My RPi HVAC Project

jason
iP

When I got my first Pi I started with some basic projects. I learned how to control relays, how to take temperature readings, how to build a LAMP stack, as well as many other projects. I learned a lot about Linux and Python.

I decide to try and control my home furnace and air conditioner from a Pi. Seemed like a simple project: read the temperature, turn the furnace on or off. It’s not that straightforward.

I got the sensors and the relays working. I stored settings and temperatures in a database. Now I needed an interface. I got a web server running and set out to build a secure interface with a public and private side that would interact with database. It didn’t take long to see that WordPress was a lot better solution than anything I could come up with.

Chromium Media Edition for RPi Pixel

jason

Chromium sucks for streaming on the Raspberry Pi Pixel Desktop. One of my gripes was Youtube TV, ‘format not supported.’ Chromium Media Edition is much better. Ventz Petkov has a sweet install script. Here’s the tl;dr version.

curl -fsSL https://pi.vpetkov.net -o ventz-media-pi
sh ventz-media-pi

Check out his article at Raspberry Pi Netflix One Line Easy Install – along with Hulu, Amazon Prime, Disney Plus, HBO, Spotify, Pandora, and many others

Vivaldi for RPi Pixel

jason

Chromium sucks for streaming on the Raspberry Pi Pixel Desktop. One of my gripes was Youtube, if I fast forward (hitting the arrow key) to advance through a video, ‘Aw, Snap!’ was sure to pop up. It’s a lot less of a problem if you’re over clocking. Chromium Media Edition has the same problem too. It’s not a problem if you’re using Vivalda.

Download Vivaldi

Grab the Linux DEB ARM version.

Start Up with New User

jason
#!/bin/bash




# Clone a user and prvileges. I got most of my information from
# https://unix.stackexchange.com/questions/204970/clone-linux-user-copy-user-based-on-another-one

# New user and password
NEW_USER=
NEW_PASS=

# user to be cloned, $USER is the current user.
SRC_USER=$USER

# get the groups the source user belongs to
SRC_GROUPS=$(id -Gn ${SRC_USER} | sed "s/ /,/g" | sed -r 's/\<'${SRC_USER}'\>\b,?//g')

# get the shell of the source user
# SRC_SHELL=$(awk -F : -v name=${SRC_USER} '(name == $1) { print $7 }' /etc/passwd)
# Rasbian defaults to bash, Ubuntu to sh. I like bash better.
SRC_SHELL='/bin/bash'

# create user then add the passwordc
sudo useradd --groups ${SRC_GROUPS} --shell ${SRC_SHELL}  --create-home ${NEW_USER}
echo "${NEW_USER}:${NEW_PASS}" | sudo chpasswd

# The new user will be asked their password and I don't like that. This stops it.
echo | sudo EDITOR='tee -a' visudo
echo '# Stop asking for my password' | sudo EDITOR='tee -a' visudo
echo "${NEW_USER} ALL=(ALL) NOPASSWD: ALL" | sudo EDITOR='tee -a' visudo




# change the timezone and here are the common US zones
#            America/New_York
#            America/Chicago
#            America/Denver
#            America/Los_Angeles
sudo timedatectl set-timezone America/Detroit




# Gotta always do this
sudo apt update
sudo apt upgrade -y
sudo apt clean

# Raspbian doesn't have git and Ubuntu doesn't have unzip.
sudo apt install git unzip -y




# # RPi4 overclocking
# sudo sed -i 's|^#arm_freq=800|arm_freq=2147|' /boot/config.txt
# sudo sed -i '/arm_freq=/ a gpu_freq=750' /boot/config.txt
# sudo sed -i '/arm_freq=/ a over_voltage=6' /boot/config.txt
# sudo sed -i '/arm_freq=/ a \\n# adding gpu_freq and over_voltage settings' /boot/config.txt

SSHFS

jason

SSHFS

sudo sshfs -o allow_other,default_permissions root@xxx.xxx.xxx.xxx:/ /mnt/droplet
sudo sshfs -o allow_other,default_permissions pi@192.168.21.84:/home/pi /mnt/hvac/home

sudo sshfs -o allow_other,default_permissions pi@192.168.21.84:/var/www/html/wp-content /mnt/hvac/wp-content

sudo nano /etc/fstab
sshfs#pi@192.168.21.84:/home/pi /mnt/hvac/home
sshfs#pi@192.168.21.84:/var/www/html/wp-content /mnt/hvac/wp-content

RPi Speed and Temp

jason
clear && printf 'current\n' && sudo cat /sys/devices/system/cpu/cpu0/cpufreq/cpuinfo_cur_freq && printf '\nmin\n' && sudo cat /sys/devices/system/cpu/cpu0/cpufreq/cpuinfo_min_freq && printf '\nmax\n' && sudo cat /sys/devices/system/cpu/cpu0/cpufreq/cpuinfo_max_freq && printf '\ntemp\n' && cat /sys/class/thermal/thermal_zone0/temp && echo

https://raspberrypi.stackexchange.com/questions/1219/how-do-i-determine-the-current-mhz

https://www.raspberrypi.org/forums/viewtopic.php?t=34994
